Ubiquiti Networks

RD-5G31-AC

airMAX® ac 2x2 PtP Bridge Dish Antenna The RocketDish™ ac Antennas feature significant advances in scalability, noise isolation, and beam performance to complement the Rocket™5ac radios for Point‑to‑Point (PtP) bridging and backhauls. They are compatible with the RocketM5; however, optimal performance requires the Rocket5ac.

RD-5G31-AC
Dimensions 748 x 748 x 349 mm (29.45 x 29.45 x 13.74 in)
Weight 7.6 kg (16.76 lb) (Mount Included)
Frequency Range 5.1 - 5.8 GHz
Gain 31 dBi
Max. VSWR 1.4:1
Wind Loading 1,028 N @ 200 km/h (231 lbf @ 125 mph)
Wind Survivability 200 km/h (125 mph)
Polarization Dual-Linear
Cross-pol Isolation 35 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, RocketM Bracket, and Weatherproof RF Connectors Included
