Ubiquiti Networks
The original NanoStation set the bar for the world's first low-cost and efficiently designed outdoor broadband CPE. The new NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors.
The Ubiquiti NanoStation M5 is the perfect device to connect networks via WLAN, whether it is a WISP or point-to-point bridge. Completely build in a UV stabilized, weatherproof case incl. an 16dBi antenna. LAN ports (RJ45) incl. PoE are contained so connections can be in case of free line of sight (LOS) established above 15km – and that for an unbeatable price!
No matter if you want to connect with a faraway WLAN or connect two networks via WLAN, the Ubiquiti NanoStation M5 is just the right choice. On the back of the NanoStation is a LED status display which helps to adjust the antenna.
Delivery contents: Ubiquiti NanoStation M5 (device), 15 Volt power supply (EU) with integrated PoE-Injector
| Product Name: | Ubiquiti NanoStation M5 5GHz 16dBi MiMo, NSM5 |
| Processor Specs: | Atheros MIPS 24KC, 400MHz |
| Memory Information: | 32MB SDRAM, 8MB Flash |
| Networking Interface: | 2 * 10/100 BASE-TX |
| Compliance: | FCC Part 15.247, CE, IC RS210, RoHS |
| TX Power: | max. 27dBm, +/-2dB bei 11a/11n |
| RX Sensitivity: | min. -83dBm +/-2dB bei 11a, min. -96dBm +/-2dB bei 11n |
| Antenna: | Integrated 14.6-16.1dBi MiMo, dual polarized |
| Beamwidth: | H 43° / V 41° |
| TCP/IP Throughput: | up to 150MBit/Sec. |
| Max Power Consumption: | Max. 8 Watts |
| Power Supply: | 15V, 0.8A (12 Watts) |
| Power Method: | Passive Power over Ethernet (pairs 4,5+; 7,8 return) |
| Operating Temperature: | -30°C to +80°C |
| Operating System: | AirOS V |
