Ubiquiti Networks
The original NanoStation set the bar for the world's first low-cost and efficiently designed outdoor broadband CPE. The new NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors.
New antenna array designs featuring 11dBi dual-polarity at 2.4GHz with optimized cross-polarity isolation and in a compact form-factor. The New NanoStation M provides a secondary ethernet port with software enabled PoE output for seamless IP Video integration.
Delivery contents: NanoStation M2 (device), 15 Volt power supply (EU) with integrated PoE-Injector
| Product Name: | Ubiquiti NanoStation M2 2.4GHz 11dBi MiMo, NSM2 |
| Processor Specs: | Atheros MIPS 24KC, 400MHz |
| Memory Information: | 32MB SDRAM, 8MB Flash |
| Networking Interface: | 2 * 10/100 BASE-TX |
| Comliance: | FCC Part 15.247, CE, IC RS210, RoHS |
| TX Power: | max. 28dBm, +/-2dB at 11b/g/n |
| RX Sensitivity: | min. -97dBm +/-2dB at 11b/g, min. -96dBm +/-2dB at 11n |
| Antenna: | Integrated 10.4-1122dBi MiMo, dual polarized |
| Beamwidth: | H 55° / V 53° |
| TCP/IP Throughput: | up to 150MBit/Sec. |
| Max Power Consumption: | Max. 8 Watts |
| Power Supply: | 15V, 0.8A (12 Watts) |
| Power Method: | Passive Power over Ethernet (pairs 4,5+; 7,8 return) |
| Operating Temperature: | -30°C to +80°C |
| Operating System: | AirOS V |
